PRODUCTS

Polytube

Features and Benefits:


• Polytube is manufactured by using advanced extrusion technology.
• Excellent characteristics of LLDPE provide durable tubing with close dimensional tolerances.
• No effect of UV radiations.
• No environment effects.
• Smooth inner surface minimizes frictional losses.
• Excellent flow characteristics.

Applications:


• Polytube is used for Online drip irrigation in open field installations of Jets Foggers, Misters, in poly/net houses.
• Use it as a connection tubes to sub-main with Inline.
• Use of Polytube for installation of Micro & Mini Sprinklers.

Available Sizes:


• Available in 12, 16, 20, 25, 32 mm

Turbo Dripper

Features and Benefits:


• Manufactured from using advanced extrusion technology.
• Turbulent flow path with wide cross sectional area makes the dripper clog resistant.
• Openable dripper – easy to clean.
• Narrow crossed shaped inlet act as filter.
• No effects of U.V. radiation and environment effects.
• Excellent flow characteristics.

Applications:


• Recommended for orchards, vegetables, fruit crops and floricultural plants on flat terrain or on moderate slopes.

Dripline K-Gol

Features and Benefits:


• Manufactured from using advanced extrusion technology.
• Excellent characteristics of LLDPE provide tubing with close
• dimensional tolerance.
• No effect of U V radiations.
• Smooth inner surfaces minimize friction losses.
• Excellent flow characteristics.
• Suitable for varying water conditions.
• Large surface inlet filters in every dripper.
• Gol Dripper designed with wide labyrinth.
• Conforms to “B” class Emission Uniformity.

Applications:


• For closed spacing crops – likes sugarcane, various types of vegetables, cotton, and medicinal plants.
• For Fruit crops like : Pomegranate, Anjeer, Banana, Mango, & Sapota.

Thin Wall Dripline K-Slim

Features and Benefits:


• A light flat integral dripper manufactured under Metzerplas novel insertion technology.
• Large inlet filter and turbulent flow pattern designed for clog resistance.
• Manufactured by using advanced extrusion technology.
• Manufactured with international standards: 12 mil.
• Smooth inner surface minimizes friction losses.
• Excellent flow characteristics.

Applications:


• For closed spacing crops like various types of vegetables, cotton, medicinal plants and other short duration close spacing seasonal crops.

Poly Fittings & Thinwall Fittings

Features and Benefits:


• Two barbs provided to prevent snap out from the tube.
• Manufactured from tough engineering plastic.
• Non-corrosive & resistant to chemicals.
• UV resistant.
• Feasible for thick wall thickness Polytube.
• Tape Lock Provision : Special Cap provided to lock the thinwall thickness tube.
• Additional front start barb provided to hold the tube.

Applications:


• Used for connection purpose for drip irrigation plain laterals and inline laterals.

Available Sizes:


• Available in 12 mm, 16 mm and 20 mm sizes.

Sand Filter

Features and Benefits:


• High quality silica crushed sand is used as a filtration media.
• Vertical shape provides more depth and degree of filtration.
• Wide space available for dirt collection which minimizes frequency of backflushing.
• Various options of backwash available like manual, semi-automatic or fully automatic backwash.
• High filtration efficiency due to uniform grade of silica.
• Sand having size 1 mm to 2 mm and outlet candles.
• Fitted with high quality & more number of Mushroom strainers for ultrafine filtration.
• Two inlets and outlets to facilitate more installations options.

Applications:


• Filtration of water in micro irrigation systems to prevent clogging due to physical and biological impurities.
• Essential use for open water sources.

Screen Filter

Features and Benefits:


• The filters are made from special chemically bonded polymer which are weather resistant.
• Clamp made out of reinforced polypropylene with plated steel for durability.
• Provided with specially designed vacuum breaker valve to avoid vacuum formation.
• Specially designed long handle for easy clamp opening.
• Low maintenance & long lasting with low pressure drop.
• Bigger port for water drainage.

Applications:


• Used as Secondary Filtration for open field sources like River, Lake, Farm pond, Open well and Storage Tank.
• Used as Primary Filtration for Tube Well, Bore Well to avoid clogging due to physical and biological impurities.

Available Sizes:


• Available in standard mesh of 120 micron size (Other mesh sizes available on demand).

Disc Filter

Features and Benefits:


• Disc filters are made with special helix system which gives better performance & results.
• Bigger drain port with 3/4’’ ball valve for quick drainage.
• DuPont Nylon hybrid clamp with SS lock for high pressure operation.
• Disc filter design for outside to inside flow.
• High filtration efficiency.
• PPGF slip-on flange for easy installation.

Applications:


• Used as Secondary Filtration for open field sources like River, Lake, Farm pond, Open well and Storage Tank.
• Used as Primary Filtration for Tube Well, Bore Well to avoid clogging due to physical and biological impurities.

Hydrocyclone Filter

Features and Benefits:


• Hydrodynamically designed to create maximum centrifugal action to separate particles heavier than water.
• Body made of reinforced engineering plastic.
• Draining facility available. Large volume of dirt collection chamber increases flushing interval.
• Equipped with Pressure Check Assembly to check pressure from inlet side and outlet side, additional Pressure check assembly provided.
• Mild steel construction.
• Efficiently removes fine sand and silt particles of size higher than 75 microns and specific gravity more than 2.65.
• Dirt can be easily flushed out through dirt collection chamber.
• Recommended to install before media/screen filters to remove particles heavier than water.
• Improves operational efficiency & life of media / screen filters.

Applications:


• Used in micro irrigation systems to remove sand and silt particles from irrigation water.

Venturi Injector

Features and Benefits:


• Venturi Injectors controlled / adjustable suction of fertilizer.
• Fertigation is based on proportionate principle.
• Uniform application of fertilizer.
• In-built check valve for protecting the injected liquid against back flow.
• With rotometer one can measure / read accurate suction of fertilizer injection rate.
• Rotometer available in all sizes.
• Saves energy & man power.
• Delivers plant nutrients directly into the crop root zone.
• Can be used with a large variety of chemicals.

Applications:


• Delivers plant nutrients directly into the wetted zone.

Plastic Header Assembly

Features and Benefits:


• Both 1″ & 1.5″ connections for air vents in single port.
• Double Pressure gauge ports with brass bushes.
• Support for assembly to maintain sturdiness.
• Made of Glass reinforced engineering plastic which is much stronger than PP.
• UV stabilized.
• Corrosion resistant, this is major problem with metal head units.
• 2 Pressure rating : 8 kg/cm2

Applications:


• Easy to install Ventury / Fertilizer Tank and Control Injection rate of fertilizer.

Available Sizes:


• 2” , 2.5” , 3”

PVC Union Ball Valve

Features and Benefits:


• Manufactured with high performance rigid PVC compound.
• Excellent chemical & corrosion resistance.
• Low frictional losses.
• Chemical resistant. nitrile rubber-O-rings makes it leak proof for longer period.
• Easy to install and dismantle.
• Available in Single and double union connection.

Applications:


• Used for flow control in irrigation & water supply lines.

Available Sizes:


• 2” , 2.5” , 3” , 4”

Butterfly Valve

Features and Benefits:


• Light Weight, easy to install.
• One Piece Body made of PVC-U.
• Disc designed to ensure low torque and low pressure loss.
• Rust Prevention: Main Parts such as disc, shaft and small parts such as bolting, washers are made of high grade stainless steel for rust prevention.
• Lock Plate : provided with throttling notches every 15° in balancing
• upto 90° or shut off service. The lever may be padlocked in any one of the notch position.
• It has EPDM rubber seal for good sealing performance.

Applications:


• Ideal application for flow control in drip irrigation system.
• It is suitable for piping in a limited space.
• It is used as control valve for filtration unit.

Available Sizes:


• 2”, 2.5”, 3”, 4”
